HT12D is a series decoder IC for remote control applications manufactured by Holtek. It is commonly used for radio frequency (RF) applications. Download. Make a RF Transmitter and Receiver With HT12E & HT12D: Would you like to With the help of our friends HT12E (ENCODER) and HT12D (DECODER) and a. The HT12D is a 2^12 decoder in 18 pin DIP package. This decoder is a series of CMOS LSIs for remote control system applications. It is paired with Holtek’s.
|Published (Last):||26 May 2005|
|PDF File Size:||18.41 Mb|
|ePub File Size:||11.29 Mb|
|Price:||Free* [*Free Regsitration Required]|
This high-density System-in-Package SiP integrates controller, power switches, and support components.
They can also be connected to LED to physically view the received data. HT12D is a decoder integrated circuit deoder belongs to 2 12 series of decoders. The data on 4 bit latch type output pins remain unchanged until new is received. This oscillator can be used by connecting these two pins through a 1M Resistor.
TL — Programmable Reference Voltage. HT12D is capable of decoding 12 bits, of which 8 are address bits and 4 are data bits. Choosing Battery for Robots. So out of the bits 8-bits will hh12d used to set address and the remaining 4-bit will be used to transmit data.
If any valid data is received they can be obtained from these four pins. In simple terms, HT12D converts the serial input into parallel outputs.
HT12D Decoder IC
This pin will go high when a data is received. Choosing Motor For Robots. It is very important that your Decoder should have the same address of that of the encoder. The input data code is decoded when no error or unmatched codes are found. The IC has a built in oscillator. These two ICs together form an Encoder and Decoder pair. It is not mandatory to use it. Decodr 4-bit data that is received can be obtained on pins AD0 to AD1 and an address of 8-bit has to be set using the pins A0 to A7.
They are paired with 2 12 series of encoders. Supply voltage; 5V 2. This pin powers the IC should use only 5V. It is mainly provided to interface RF and infrared circuits. Interface GPS with Arduino.
The serial input data is compared with the local addresses three times continuously. What is Web Browser. For decoding a data the IC will requires an oscillatorluckily this IC has one in-built.
Virgin Galactic — Commercial Space Flight. This oscillator can be used by connecting these two pins through a 1M Resistor 17 Valid Transmission VT This pin will go high when a data is received.
So if you are working on a project which has to transmit a 4-bit data from one end to other either by wire or wireless then this IC pair will be best suited for you. If you want security you can connect any of the 8 pins to 5V to make it high.
In the above circuit I have set the 8-bit address data as 0b, by connecting all address pins to ground. Can be used in Home automation for short range remote switching Safety systems like Burglar alarm system, Smoke or Fire alarm system etc. It decodes the serial addresses and data received by, say, an RF receiver, into parallel data and sends them to output data pins.
We should set the bits in same pattern on Encoder and Decoder IC to pair them. A basic circuit diagram for the HT12D IC is shown below In the above circuit I have set the 8-bit address data as 0b, by connecting all address pins to ground.
HT12D RF Decoder IC Pinout, Details, Equivalent & Datasheet
SPI Module of Arduino. This series of decoders are mainly used for remote control system decoxer, like burglar alarm, car door controller, security system etc. Interface SD Card with Arduino. Skip to main content. Valid transmission; active high.
